1.2N.M Hybrid Stepper Motor

NEMA23 1.2N.m 2 phase hybrid bipolar stepper motor 1.8 stepping motor for Office     Automation

   Product description of 1.8 stepping motor

• Automatic machine operation, stable automatic work, high processing efficiency.
• Online testing of technical parameters to ensure the consistency of data product parameters
• Electromagnetic furnace optimization design, lift torque, reduce temperature rise, so that the motor running smoothly
• The material is selected from well-known manufacturers at home and abroad. The advantages are light weight, good heat dissipation performance, good thermal conductivity, die-casting, good plasticity, higher elongation than iron, low noise, good motion stability, the disadvantages are high price, low hardness
• Material quality: The coat is 304 stainless steel, the water jacket is the high compression casting aluminum tube, the red copper coil.

Specifications

• Speed/Torque Characteristics(Reference Value)

​

• Application
•
• Our products are widely used in 3d and inject printers, CNC routers, Engraving Machines, Stage Lighting Control, Security Surveillance, Video Equipment, Laser workstation, Carving Machine, Office Automation,Smart Toy, Digital Controlled Machinery,Analytical and Medical In struments,Textile Equipment, Embroidery Machine, Precision Telescope Positioning Systems, High Speed Dome Camera,Robotic and other automatic equipment.

   Quality control process:

• Incoming inspection: The inspection shall be conducted according to the Requirements of the Incoming Inspection Specification or the product drawing
• Monitoring and measurement of production process (self-inspection - inspection - batch production)
• Final inspection and test
• All inspectors must be trained and then put on duty
• Nonconforming products shall be executed in accordance with Nonconforming Product Control Procedures

1. Raw material inspection
2. Inspecting according to the standard of testing raw material or the drawing
3. Monitoring and measurement in production process
4. Self checking-tested by QC-Batches production
5. Final checking and make experiment
6. All products should be through testing by the professional equipment
